Scrapy Proxy Waterfalling: How to Waterfall Requests Over Multiple Proxy Providers
A very common requirement for many web scrapers is designing a system that can waterfall requests over mutliple proxy providers to increase reliabilty and decrease costs.
Proxies can be tempermental. They might work today for a particular website, but not tomorrow. And can vary massively in price.
So a common strategy most developers use, is to have proxy plans with a number of proxy providers and distribute their requests amongst.
In this guide, we're going to go through how you can build a custom proxy waterfalling middleware for Scrapy:
- Our Proxy Waterfalling Strategy
- Building The Proxy Waterfall Middleware
- Integrating Our Proxy Waterfall Middleware Into Spiders
First, let's discuss our proxy waterfalling strategy.
Need help scraping the web?
Then check out ScrapeOps, the complete toolkit for web scraping.
Our Proxy Waterfalling Strategy
Your proxy waterfalling system can be as complex or as simple as you need it to be based on your own requirements and objectives. In this guide, we're going to focus on a couple key objectives:
- Use no proxy on first request, to save on proxy costs.
- Using the cheapest working proxy for a particular website.
- Increasing reliability by falling back to better (more expensive) proxies if others are failing.
- Ability to use specific proxies for specific websites.
You could make this middleware more advanced by adding in the functionality to customise proxy parameters (geotargeting, JS rendering, etc.) based on flags set in the request, manage user-agents, or validate responses on the fly. However, for this guide we're going to cover the essentials as you should be able to expand it if you need to.
For this guide we're going to use 3 proxy providers:
With Scrapingdog being the cheapest, followed by ScraperAPI and then Scrapingbee.
Building The Proxy Waterfall Middleware
To build the proxy waterfall middleware we are going to create a new DownloaderMiddleware in our projects middleware.py file, then complete the following steps:
- Create Outline of Middleware
- Setup Proxies Upon Launch
- Function To Set Proxy On Request
- Architect Our Proxy Waterfall
Let's get started.
1. Create Outline of Middleware
First things first is that we will outline the middleware. Which thanks to Scrapy is already pretty well defined.
For this middleware, we only care about setting up the middleware on launch and adding proxies to incoming requests so we just need to use the from_crawler, __init__, and process_request functions available in Scrapy middleware classes. We will also create a api_key_valid and add_proxy to keep our code clean.
## middleware.py
class ProxyWaterfallMiddleware:
@classmethod
def from_crawler(cls, crawler):
return cls(crawler.settings)
def __init__(self, settings):
# Where we set up the middleware at launch.
pass
def api_key_valid(self, api_key):
# This is a custom function, where we will use this to make sure we have
# a valid API key for the proxy before using it.
pass
def add_proxy(self, request, username, password, host):
# This is a custom function, where we will use to set a proxy on a request.
pass
def process_request(self, request, spider):
# Event listen function in Scrapy where we will implement the waterfall system.
pass
2. Setup Proxies Upon Launch
The first bit of functionality we need to create is to setup the middleware on launch, by loading in our proxy provier API keys from the settings.py file and then define the proxy username, password, and host for each proxy provider. We do this in the __init__ method.
## middleware.py
class ProxyWaterfallMiddleware:
@classmethod
def from_crawler(cls, crawler):
return cls(crawler.settings)
def __init__(self, settings):
self.scraperapi_api_key = settings.get('SCRAPERAPI_API_KEY')
self.scrapingbee_api_key = settings.get('SCRAPINGBEE_API_KEY')
self.scrapingdog_api_key = settings.get('SCRAPINGDOG_API_KEY')
## Scrapingbee
self.scrapingbee_http_address = 'http://proxy.scrapingbee.com:8886'
self.scrapingbee_username = self.scrapingbee_api_key
self.scrapingbee_password = 'render_js=False'
## ScraperAPI
self.scraperapi_http_address = 'http://proxy-server.scraperapi.com:8001'
self.scraperapi_username = 'scraperapi'
self.scraperapi_password = self.scraperapi_api_key
## Scrapingdog
self.scrapingdog_http_address = 'http://proxy.scrapingdog.com:8081'
self.scrapingdog_username = 'scrapingdog'
self.scrapingdog_password = self.scrapingdog_api_key
def api_key_valid(self, api_key):
if api_key is None or api_key == '':
return False
return True
def add_proxy(self, request, username, password, host):
# This is a custom function, where we will use to set a proxy on a request.
pass
def process_request(self, request, spider):
# Event listen function in Scrapy where we will implement the waterfall system.
pass
Each proxy provider has a slightly different layout in terms of what values up put in the username, password, and host so we've had to define them seperatly.
We also, created the api_key_valid method which will be used later on to make sure we have a valid API key before sending a request with a proxy.
3. Function To Set Proxy On Request
Next, we're going to create the add_proxy which will be used to set a proxy for each request, and import the base64 library so we can encode the user credentials.
## middleware.py
import base64
...
def add_proxy(self, request, username, password, host):
user_credentials = '{user}:{passw}'.format(user=username, passw=password)
basic_authentication = 'Basic ' + base64.b64encode(user_credentials.encode()).decode()
request.meta['proxy'] = host
request.headers['Proxy-Authorization'] = basic_authentication
This takes in the with the username, password and host of the proxy we want to use and applies them to the Request we provide.
4. Architect Our Proxy Waterfall
Finally, we have everything we need to create our proxy waterfall system.
We're going to architect it as follows:
- Always use ScraperAPI when scraping Google as they don't charge extra for Google requests.
- Other then scraping Google, make the request without a proxy to try and reduce costs.
- Use Scrapingdog for the first 2 retries.
- Use ScraperAPI for the 3rd & 4th retry.
- Use Scrapingbee for all other retries.
If one of the proxies isn't enabled (checks if no API key set with check_api_key_valid), the the proxy middleware will fallback to the next proxy in the waterfall. The final middleware looks like this:
## middleware.py
import base64
class ProxyWaterfallMiddleware:
@classmethod
def from_crawler(cls, crawler):
return cls(crawler.settings)
def __init__(self, settings):
self.scraperapi_api_key = settings.get('SCRAPERAPI_API_KEY')
self.scrapingbee_api_key = settings.get('SCRAPINGBEE_API_KEY')
self.scrapingdog_api_key = settings.get('SCRAPINGDOG_API_KEY')
## Scrapingbee
self.scrapingbee_http_address = 'http://proxy.scrapingbee.com:8886'
self.scrapingbee_username = self.scrapingbee_api_key
self.scrapingbee_password = 'render_js=False'
## ScraperAPI
self.scraperapi_http_address = 'http://proxy-server.scraperapi.com:8001'
self.scraperapi_username = 'scraperapi'
self.scraperapi_password = self.scraperapi_api_key
## Scrapingdog
self.scrapingdog_http_address = 'http://proxy.scrapingdog.com:8081'
self.scrapingdog_username = 'scrapingdog'
self.scrapingdog_password = self.scrapingdog_api_key
def api_key_valid(self, api_key):
if api_key is None or api_key == '':
return False
return True
def add_proxy(self, request, username, password, host):
user_credentials = '{user}:{passw}'.format(user=username, passw=password)
basic_authentication = 'Basic ' + base64.b64encode(user_credentials.encode()).decode()
request.meta['proxy'] = host
request.headers['Proxy-Authorization'] = basic_authentication
def process_request(self, request, spider):
retries = request.meta.get('retry_times', 0)
## Always Use ScraperAPI for Google.com
if 'google.com' in request.url and self.check_api_key_valid(self.scraperapi_api_key):
self.add_proxy(request, self.scraperapi_username, self.scraperapi_password, self.scraperapi_http_address)
return None
## No Proxy --> Use No Proxy On First Request
if retries == 0:
return None
## Proxy Tier #1 --> Use Scrapingdog For All Requests For First 2 Retries
if self.check_api_key_valid(self.scrapingdog_api_key) and retries <= 2:
self.add_proxy(request, self.scrapingdog_username, self.scrapingdog_password, self.scrapingdog_http_address)
return None
## Proxy Tier #2 --> Use ScraperAPI For All Requests For 3rd & 4th Retry
if self.check_api_key_valid(self.scraperapi_api_key) and retries <= 4:
self.add_proxy(request, self.scraperapi_username, self.scraperapi_password, self.scraperapi_http_address)
return None
## Proxy Tier #3 --> Use Scrapingbee For All Requests Aftr 5 Retries Or As Fallback
if self.check_api_key_valid(self.scrapingbee_api_key):
self.add_proxy(request, self.scrapingbee_username, self.scrapingbee_password, self.scrapingbee_http_address)
return None
Now with the ProxyWaterfallMiddleware complete, we just need to enable it.
Integrating Our Proxy Waterfall Middleware Into Spiders
Integrating the ProxyWaterfallMiddleware we just created is very simple. We just need to update our settings.py with our proxy API keys and enable the middleware in our download middlewares.
## settings.py
SCRAPERAPI_API_KEY = 'YOUR_API_KEY'
SCRAPINGBEE_API_KEY = 'YOUR_API_KEY'
SCRAPINGDOG_API_KEY = 'YOUR_API_KEY'
DOWNLOADER_MIDDLEWARES = {
'proxy_waterfall.middlewares.ProxyWaterfallMiddleware': 350,
}
Now, whenever you run a spider your requests will be routed through the Proxy Waterfall middleware and it will select the best proxy based on the criteria you have defined.
More Scrapy Tutorials
That's how you can create your own proxy waterfall system to help you lower proxy costs whilst also increasing reliability. This middleware can be easily customised and extended for your own project requirements.
